History
Complete ground up circuit race car project based on the 1990’s Alfa ROmeo "Superturismo" circuit race cars in Italy.
Modifications
According to 1991 Competition in Italy group A (CSAI) (Commissione Sportiva Automobilistica Italiana)
Specification sheet:
Engine:
1712cc Quad cam 16V 4 cylinder Boxer
Fuel Injected Quad throttle bodies
Custom Designed Ram air cold air intake
Enlarged baffled sump – cap. 6.8L
External 13 row front mounted oil cooler
Oil breather separator reservoir in aluminium
Fuel System:
Twin Bosch Motorsport EFI fuel pumps ( One acts as lift pump to swirl pot)
Aeromotive Adjustable fuel pressure regulator
2.0 L boot mounted Aluminium swirl pot
Twin EFI fuel filters
Ignition:
Electronic Distributor Bosch
Bosch ML 4.1 ECU with Performance chip to adjust fuel and ignition curves
Exhaust:
4-2-1 Headers
--- Inch Race exhaust system ( all mandrel bends)
Rear straight through silencer “Stainless steel"
Rear exit twin outlet exhaust
Brake System:
FRONT:
4 Piston Brembo Calipers
OMP ( Italy) RACING GRADE brake pads
282mm Slotted and vented front rotors
Goodridge Braided brake line
REAR:
Single piston callipers
OMP RACING GRADE brake pads
240mm Slotted and vented rotors
Goodridge braided brake lines
Wilwood Adjustable brake bias valve ( front to rear)
Weight:
820 KG dry
Power to weight : 190HP P/tone
